  IPP720 IPP960 IPP1050 IPP1300
Installation area 20m(W)×20m(H)×6m(H) 25m(W)×20m(H)×6m(H) 25m(W)×20m(H)×6m(H) 10m(W)×15m(H)×6m(H)
Required power 400KW

600KW

600KW

400KW

Total weight 7.5Ton 10Ton 12Ton 14Ton
Press pressure 15Ton/Unit 60Ton/Unit 60Ton/Unit 60Ton/Unit
Standard set 3 set 3 set 3 set 1 set
Equipment production time 80days 90days 90days 75days
Equipment Installation time 20days 25days 25days 15days
Education time 15days 15days 15days 15days
Required worker 4 people 4 people 4 people 2 people
  IPP2430 IPP960FD IPP1300FD
Installation area 20m(W)×20m(H)×6m(H) 26m(W)×20m(H)×5m(H) 30m(W)×20m(H)×5m(H)
Required power 580KW 600KW 400KW
Total weight 25Ton 14Ton 20Ton
Press pressure 120Ton/Unit 60Ton /Unit 60Ton /Unit
Standard set 1 set 3 set 1 set
Equipment production time 85days 90days 75days
Equipment Installation time 20days 25days 20days
Education time 15days 15days 15days
Required worker 2 people 3 people 2 people

1. MOLDING LIST
1. Suction Part
2. Up/Down Block Part
3. Transfer Block Part
4. Frame Part

2. VACUUM PARTS
1. Pump Type: Liquidring Pump
2. Vacuum Pressure : 680mmHg
3. Motor : ,380v,3Phase
4 Dewatering Section
5. Vacuum Section

3. HYDRAULIC PARTS
1. Oil pump Type : Double Vane Pump
2. Motor : 380V,3Phase
3.Pressure : Normal 70K, Max 140K

4. CONTROL PANEL PARTS
1. Heater Panel : SCR Control
2. MCC Panel
3. PLC Panel
4. Touch Screen

5. COMPRESSOR PART
1. Screw type air compressor
2. Motor : 380V
3. Air dryer
4. After cooler
5. Air receiver tank
6. Main , pre, line filter

6. TANK PARTS
1. Supply Tank
2. Storage Tank
3. White Water Tank
4. Sealing Water Tank(PE)
5. Fresh Water Tank (PE)

7. PULPER
1. Square Type
2. Capacity :5㎥
3. Pulping Consistency : Max 2%
4. Motor : 380V,3Phase
